Fundamentals of Garbage Collection

1.Introdiction to .NET Memory Management

When a .NET application runs, memory is primarily divided into two areas:

• Stack

• Heap

Local variables and method calls are handled by the Stack.
Objects created using the new keyword are allocated on the Heap

But this raises an important question:

If objects are continuously allocated on the heap, who deletes them?

In languages like C and C++, developers must manually release memory using mechanisms such as free() or delete. Failure to do so can result in memory leaks, dangling pointers, or memory corruption.

In contrast, .NET uses an automatic memory management system called the Garbage Collector (GC).

The Garbage Collector automatically identifies objects that are no longer in use and reclaims their memory, allowing developers to focus on application logic rather than manual memory cleanup.

What is Stack.?

The Stack is a region of memory used to manage method execution.

It is responsible for storing:

• Method parameters

• Local variables

• Return addresses

• Execution context

When a method is called, a stack frame is created.
Each stack frame contains everything required for that specific method call.

When another method is called inside it, a new stack frame is placed on top of the previous one.

This is why it is called a Stack —
because data is added and removed in a Last-In, First-Out (LIFO) order.

What Happens When a Method Returns?

When a method finishes execution:

• Its stack frame is removed.

• All its local variables go out of scope.

• The memory used by that frame is automatically reclaimed.

If the method that called it also returns, its stack frame is removed as well. Eventually, if all methods complete, the stack becomes empty again. Stack memory management is extremely fast because it simply moves a pointer up and down.

when code call another method

same thing happened again it added, Method parameters, return address, and local variables on top of previous stack frame.

why it called stack.? because information will get stacked on top of another

what happened when will u return result from method.? so in this at moment when you return, all the local variables go out of scope and are destroyed. and if return from first method also we will back at where we started, empty stack

What is Heap.?

this is also a block of memory, every new object in .NET is creating into heap like

MyClass Obj = new MyClass();

lets see an program

using System;

class Person
{
    public string Name;
    public int Age;

    public void Greet()
    {
        Console.WriteLine($"Hi, I am {Name} and I am {Age} years old.");
    }
}

class Program
{
    static void Main()
    {
        Person p1 = new Person();
        p1.Name = "Hasan";
        p1.Age = 25;

        p1.Greet();
    }
}

First, p1 is created in the Stack as a reference variable. At this moment, it does not hold an object; it only has space to store a memory address and initially contains null.

Then the new Person() statement executes. This allocates memory in the Heap and creates a new Person object there. The fields of the object are automatically initialized with their default values (Name = null, Age = 0).

After the object is created in the Heap, its memory address is assigned to the reference variable p1 in the Stack. Now p1 points to that Heap object.

When we assign values using p1, such as setting properties or fields, those values are stored inside the Heap object. The Stack continues to store only the reference (memory address), while the actual object data resides in the Heap.

now on stack method will reference from heap memory.

if method if return i will removed from stack but in heap will still exist like

This is interesting, right? When a method finishes executing, its local variables and parameters go out of scope, but the object in the heap may still exist. In this case, the object becomes dereferenced because the variables and parameters that were referencing it have gone out of scope. A dereferenced object continues to exist in the heap, but it is not released immediately. Instead, it becomes eligible for garbage collection, and the .NET runtime will clean it up later.

The .NET Framework postpones cleaning up dereferenced objects because heap cleanup takes time. By delaying this process, the application can run more efficiently and perform better. This cleanup process is called garbage collection, and it runs periodically in the background.

When the runtime starts garbage collection, it scans the heap and identifies objects that are no longer referenced by any active variables, parameters, or reachable objects in the program. It then deallocates those unreachable objects and frees the memory.

How Data Stores in Stack & Heap

In our code have Used parameters like Integer & String
The int type belongs to a special category called value types. Value types store their actual data directly in the memory location where they are declared.

If a value type variable (like int) is declared inside a method, its value is stored directly in the Stack as part of the method’s stack frame. When the method ends, the stack frame is removed, and the value is automatically destroyed.

If a value type is part of an object (for example, int Age inside a class), it is stored in the Heap because it becomes part of the object’s memory block.

Reference types (such as class, string, and array) work differently. The reference variable is stored in the Stack, but the actual object is created and stored in the Heap. The Stack holds only the memory address, while the object’s data remains in the Heap.

Value Type:-

A value type is a type of variable in which both the type and the actual value are stored together in memory. The variable directly contains its data rather than a reference to another memory location.

For example, if I declare a local integer variable with a value of 1234, both the int type and the value 1234 are stored together in the Stack as part of the method’s stack frame. The variable itself holds the actual data, not a memory address pointing somewhere else.

This is why value types are typically faster to access and automatically removed when the method’s stack frame is destroyed.

All Value type

See All Value Type

sbyte	long
byte	float
char	double
short	decimal
unsort	bool
int	enum
unit	struct

Reference Type:-

a reference type is a type of variable that refers to a value stored on the heap. in this variable can be on stack but i will refer a value on heap
reference type can exist on the stack and on the heap just like value types, but they will always refer to a value on heap.

lets have variables A and B and variable a an object and b is null, what happens when i will assign a = b,

The reference of a will copied into b (this is an imp feature of reference type)

what happens when i will compare a and b?

they are two different variables that refers same object on the heap
well in this scenario these two will equal...

wait
what what happens when i will compare a and b having 2 object in heap with identical data.?

so in this scenario it will not consider as equal, because the references are diffrent.

• Reference types can be set to the null value.

• Reference types store a reference to their value.

• And this value is always stored on the heap.

• Reference types can exist on the stack and on the heap, but their value is always stored on the heap.

• Reference types are assigned by reference, meaning the reference is copied over.

• Reference types are compared by reference to variables referring to the same object are considered equal.

• And two variables referring to separate but identical objects are considered not equal.

Boxing and Unboxing

Boxing and Unboxing is a process to convert value type to reference type like
int is value type convert as object

int number = 10;      // value type (stored in stack)
object obj = number;  // boxing
int number2 = (int)obj  //unboxing

what will happen here ? as respect of Memory

Boxing is the process of taking value types on the stack, packing them into objects and placing these objects on the heap. Boxing happens whenever you assign a value type to a variable parameter field or property of type object.

Unboxing is the reverse process. Objects on the heap are unpacked and the value types inside are copied back to the stack. Unboxing happens whenever you have an object value and you cast it to a value type.

This article focused on building strong fundamentals of .NET Garbage Collection.

In upcoming articles, we will go deeper into:

• Generational GC architecture and allocation behavior • Finalization lifecycle and Dispose pattern • GC pauses, Large Object Heap and performance tuning strategies • Real-world memory optimization techniques used in production systems

Follow the series to continue the deep dive.
